The Navy has a blind spot about offensive mining, but technological advances and a new concept of operations could make it a game changer.
Ask almost any U.S. Navy officer about mine warfare and the reply most likely will center on efforts to recapitalize the service’s surface and airborne mine countermeasures capabilities. It would be unusual to receive a response that has anything to do with the actual use of maritime mines by the United States or friendly nations.
Indeed, an internet search for the United States’ current offensive mine capabilities yields a disappointing response.1 The nation currently employs only two maritime mines: the Quickstrike family, which converts different sizes of air-launched general-purpose bombs into mines by attaching a simple target-detection device; and the submarine-launched mobile mine (SLMM). Both use 20th-century technology and are useful only in shallow water directly underneath a target vessel.
Meanwhile, a similar search of most competitor and adversary nations reveals a long-held recognition of the high leverage of offensive mining capability. These nations’ inventories are extensive and growing in sophistication.
The U.S. Navy is the world’s most recent victim of these inexpensive but disproportionately effective weapons. The USS Samuel B. Roberts (FFG-58) struck an Iranian mine and nearly sank in 1988. The USS Tripoli (LPH-10) and USS Princeton (CG-59) both struck Iraqi mines on the same day in 1991 during Operation Desert Storm, resulting in mission kills for both ships. Partly because of concerns over the threat of mining, U.S. Central Command only feinted landing an amphibious force in Kuwait during the same conflict.
At left: Adversaries have long recognized the high leverage of an offensive mining capability. During Operation Desert Storm, the USS Tripoli (LPH-10), shown here, and USS Princeton (CG-59) fell victim to Iraqi mines. Concerns over the mine threat contributed to U.S. Central Command’s decision to only feint an amphibious force landing during that conflict.
The Navy’s response has been to dedicate additional resources and intellectual firepower to countermine warfare in an effort to preserve its freedom of maneuver. However, the service has overlooked the other half of the lesson: mines are a cheap and disruptive weapon in naval warfare.
This seeming blind spot exists despite the U.S. Navy’s own history of using these weapons with decisive effect. According to the service’s own website, in World War II, “U.S. aircraft laid over 12,000 mines in Japanese shipping routes and harbor approaches, sinking 650 Japanese ships and totally disrupting all of their maritime shipping.”2 The U.S. mining of Haiphong Harbor in Vietnam in 1972 helped bring that nation to the peace table.
Even Chinese Navy officials recognize this blind spot, stating that “relative to other combat mission areas, [the U.S. Navy’s] mine warfare capabilities are extremely weak.”3
There are several reasons offensive mine warfare has atrophied within the Navy. First, U.S. combatant commanders have not been clamoring for the weapon, preferring instead more traditional ways of waging war. Second, no powerful warfare or resource sponsor for mine warfare exists who can pound the table for the modest resources required to build the type of capability a first-rate naval power would possess. Third, mine warfare seems to U.S. Navy culture like something that would be used only by smaller and weaker navies, rather than by the world’s leading naval combat power.
Finally, some believe the United States should not invest in advanced mining capability because of misconceptions regarding whether international law allows the use of sea mines (to say nothing of the stigma accompanying weapons that lie in wait and have no direct human interaction). It is useful to explore this point a bit further.
The air-launched Quickstrike is one of only two U.S. maritime mine families and is useful only in shallow water. The Navy should be looking to develop a smart device with two-way communications capability, significant computing power, and the ability to deploy from a variety of platforms.
Mines and the law
The only treaty explicitly governing the use of sea mines is the Convention of 1907 Relative to the Laying of Automatic Submarine Mines (otherwise known as Hague VIII). It applies only during and after conflict, and only to contact mines and torpedoes. All other governance exists as international law derived from other related agreements or as state practice.
Naval mines clearly are lawful weapons. The rules concern their application, which depends on how (for military or civilian targets), where (territorial or international waters), when (peacetime or wartime), and why (self-defense or aggression) a state intends to use them. Mines may be used for a blockade, but their use must be able to discriminate between innocent ships and combatants. Hague VIII, as well as the law of war principle of distinction, prohibits the use of mines for the sole purpose of interdicting innocent commercial shipping.
One commonly accepted principle is that states are prohibited from laying mines in the territorial seas of another nation or in international waters in peacetime. U.S. policy, however, stipulates that the laying of controlled mines (mines that require an affirmative action to be armed) in international waters even in peacetime is legal “if they do not unreasonably interfere with other lawful uses of the ocean” and allows factoring in self-defense, including collective self-defense, concerns.4
The bottom line is that international law provides ample opportunities for the use of sea mines. Nonetheless, emphasis on more traditional warfighting concepts has left little room for emphasis on offensive mine warfare in the U.S. Navy. Indeed, the U.S. Air Force has focused at least as much on offensive mine warfare as the Navy, maintaining an active inventory of Quickstrike mines for use in potential future conflicts (including a new version capable of being launched from standoff range and gliding to its target).
But the world is changing rapidly for the U.S. Navy. The forward, extended range, and exposed nature of Navy operations is colliding with the rapid progress competitor nations are making in closing once-undisputed capability gaps and creating new, unfavorable ones in what often is billed as antiaccess/area denial warfare. In addition, at a time of uncertain budgets, the services should be looking for higher leverage methods of conducting warfare. It makes sense to open the door to new operational concepts—or to revive old ones—and mate them with modern technology to present new dilemmas for potential competitors. At the forefront of this should be offensive mine warfare. We are way behind, and we need to catch up.
The art of the possible
What could a modern-day mine, using advanced technology coupled with an imaginative concept of operations, look like?
To begin with, the Navy should seek more than just a mine. It should be looking for a weapon attached to a sensor, not a sensor attached to a weapon, so it probably should not even be called a mine. For now, let’s just call it “the device.”
Ideally, the device would possess the following characteristics, all of which are technically feasible but would need to be assembled in a new combination:
• Secure communications. The device should be able to conduct secure two-way communications, most likely using a retractable buoy that normally remains just below shipping traffic or fully retracted. The buoy would rise to the surface according to its most recent instructions, either periodically or based on conditions. Its link would employ a variety of radio frequency bands and interface platforms (including an increasing proliferation of commercial satellites) in a high-data-rate, low-probability-of-intercept, low-vulnerability-to-jamming regime. The device would lower its acoustic and communications tether upon the approach of a fishing vessel (or threat) to avoid entanglement. The device would need to be both tamper proof and cyber secure.
• Machine intelligence. The device would use significant computing power, machine learning, and sophisticated algorithms to enable a wide variety of techniques and operating modes. Its software would be updatable over the communications link in much the same way satellites accept software upgrades.
• Command and control. With its carefully managed communications capability, the device could accept commands, download acoustic library updates, and transmit intelligence, engagement, location, and health reports. Its antenna would resubmerge when complete. Future concepts might call for acoustically controlled (and even networked) mines, but this capability remains a major technical challenge. A simple encoded acoustic trigger, however, would be simple to install and could be used in extremis to direct the device to establish communications (for example, to reset to a nonhostile mode).
• Detection and discrimination. The communications tether would be strung with acoustic, temperature, and salinity sensors so the device understands the water column in which it is placed. The device itself would employ sensitive hydrophones and other sensors. When coupled with a sophisticated acoustic library updated through the communications link, the device would be able to discriminate contact types, and the richness of the library would improve over time.
• Lethality. The device would be capable of carrying one or more small torpedoes designed to enable mission kills of selected platforms. This provides two key advantages. First, it would allow the device to operate in deeper water than current mines. Second, it would yield a much greater engagement radius than current mines.
• Signature: The device should be acoustically difficult to find and sweep.
• Modularity. The device should be deployable as either a sensor with weapons attached or as only a sensor (with the capability to add weapons on site later).
• Endurance and reliability. The device’s endurance would depend largely on its use of computing power and its operating mode (which would drive communications duration and frequency). It would employ advanced battery technology, as well as the ability for either on-site battery replacement or recharging through the device’s tether using some type of servicing vehicle. Potential technologies exist that could provide for trickle charging based on tidal and wave action on the communications tether.
• Deployability. The device would be deployable from a variety of platforms, including ships (the DDG-1000 class is uniquely suited for this role), submarines, aircraft, and unmanned underwater vehicles. Providing the device its own mobility would be attractive, but doing so would add enormous complexity and cost.
Such a device would have a variety of operating modes:
• Peacetime. The device would serve as an intelligence collection platform; indeed, in this role it might not even be equipped with a weapon. As needed, collected acoustic information could be sorted using on-board algorithms to periodically transmit detailed acoustic data for high-interest contact types (which would be used to build the measurement and signature intelligence database) and only traffic pattern information for lower interest contacts.
• Heightened tensions. The device could be directed during one of its communications events to make itself available more frequently until told otherwise (recognizing this would cost battery life). Such events also could shift the device’s reporting mode to further protect its autonomy. It also could be directed during one of its communication events to shift to sending only tailored high-priority indications and warnings to further protect its signature.
• Hostilities. At the commencement of hostilities, the device could be shifted into one of a number of engagement modes. For example, it could be directed to engage all military platforms. Or it could be directed to engage only certain particular platform types (among submarines, surface combatants, amphibious ships, etc.). It would be able to report an engagement and its probable outcome.
• Posthostilities. The device could be reset to a lower level mode upon the moderation of tensions or cessation of hostilities, either through an acoustic signal, an acoustic signal that directs an immediate communications event, or when the device next establishes communications.
This is doable
In their best seller The Second Machine Age, Erik Brynjolfsson and Andrew McAfee make the point that “the true work of innovation is not coming up with something big and new, but instead recombining things that already exist.”5 Much, if not all, of the technology needed to bring the United States’ offensive mine warfare capabilities into the 21st century exists. Software development for the device would be a fascinating project. Both the traditional defense industrial base and nontraditional innovation bases are capable of developing or contributing to this capability. Someone just has to ask them to do it. It is a perfect candidate for the Defense Department’s renewed emphasis on rapid, fail-fast prototyping and acquisition.
This capability would be a game changer for combatant commanders: imaginative planners are more than capable of exploring the new concepts of operation it would enable. Key operational questions would be why, when, where, and how to emplace such devices. These decisions would be based on a host of factors, including whether the full capability was installed (e.g., inclusion of the weapon), the probability of detection of both the laying activity and the devices themselves, and levels of tension. With its ability both to discriminate and to be remotely activated and deactivated, the device would make U.S. mines even more compliant with international legal concerns. As such, the nation would be more willing to employ them without fear of international opprobrium.
Advanced offensive sea mines would pose a high-leverage deterrence dilemma to competitor nations should they threaten the United States or its allies or friends. Because of their dramatically expanded employment capability, these sensors and weapons could be deployed with lower risk to conventional U.S. forces and with no concerns over host-nation permissions. As the technology matures to allow acoustic control, more advanced deep-water capability using the same concept and a different weapon could interdict threats to our homeland as they pass through strategic choke points en route to positions off the U.S. coast. They also eventually could be used to protect undersea cables, which are a key area of vulnerability for the U.S. economy.6
The legal, technical, and conceptual challenges to developing and employing such a device are surmountable. It will not be enormously expensive to develop or procure. The only question will be whether cultural and programmatic challenges will continue to stand in the way. Of one thing we can be nearly certain: if the United States does not do this, another nation probably will . . . and probably already is.
1. For purposes of this discussion, offensive mine warfare includes use of mines for defensive purposes. The term is used to distinguish between a nation’s own use of mines and countermine warfare.
2. “U.S. Navy Mines,” Fact File.
3. As quoted by Andrew S. Erickson, Lyle J. Goldstein, and William S. Murray in “Chinese Mine Warfare: A PLA ‘Assassin’s Mace’ Capability,” Naval War College China Maritime Studies Number 3 (Naval War College Press, 2009), 1.
4. “DoD Law of War Manual,” § 22.214.171.124.
5. Erik Brynjolfsson and Andrew McAfee, The Second Machine Age: Work, Progress, and Prosperity in a Time of Brilliant Technologies (New York: W. W. Norton and Company, 2014), 78.
6. Tim Johnson, “Here’s How to Shut Down the Internet: Snip Undersea Fiber-Optic Cables,” McClatchy DC Bureau, 11 December 2017.
Admiral Winnefeld retired from the Navy in 2015 after serving as the ninth vice chairman of the Joint Chiefs of Staff.
Captain Ahmad retired from the Navy in 2016. His last assignment was as staff judge advocate to U.S. European Command.
